Southwire F40015-1A 18 sol cu 2/c oas cmr/cmg/cl3r/fplr pvc 300v 1000 ft Trusted Brand

The SOUTHWIRE F40015-1A is an 18 AWG solid bare copper, 2-conductor, overall shielded (OAS) cable. Designed for fire protective signaling circuits, smoke detectors, voice communications, audio control, and initiating circuits, it features Low Smoke Polyvinyl Chloride (LS-PVC) insulation and an aluminum foil shield. This cable complies with Article 760 of the NEC and operates within a temperature range of -10°C to 60°C. It includes a rip cord for convenient jacket removal.

• Designed for fire protective signaling circuits, smoke detectors, and voice communications.
• Features Low Smoke Polyvinyl Chloride (LS-PVC) insulation and an aluminum foil shield.
• Complies with Article 760 of the NEC and includes a rip cord for jacket removal.

Product Highlights

Overall shielded 18 AWG 2-conductor cable for fire alarm and communication systems, featuring LS-PVC and NEC compliance.

Product Information

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: F40015-1A
• Country of Origin: United States of America

Technical Specifications

• Cable Type: FPLR Riser
• Conductor Size: 18 AWG
• Conductor Count: 2
• Conductor Material: Solid bare copper
• Conductor Stranding: Solid
• Outer Diameter: 0.153 in
• Insulation Material: Low Smoke Polyvinyl Chloride (LS-PVC)
• Jacket Material: Low Smoke Polyvinyl Chloride (LS-PVC)
• Jacket Color: Red
• Shield Type: Overall Foil Shield
• Shield Material: Aluminum foil
• Drain Wire: 24 AWG tinned copper
• Rip Cord: Included
• Length: 1000 ft
• Voltage Rating: 300V
• Min Operating Temperature: -10°C
• Max Operating Temperature: 60°C
• DC Resistance at 25C: 6.669 ohms/1000ft
• Allowable Ampacity: 14 A (Raceway 90C)
• Minimum Bend Radius: 0.9 in
• Approximate Weight: 16 lbs/1000ft
• Sunlight Resistant: Yes
• Standards & References: UL 1424, UL 13, UL 444, ASTM B3, ASTM B33, NFPA 70, NFPA 101, NFPA 130, NFPA 502, RoHS-2
• Armor: Unarmored
