Limited Offer Bussmann FRN-R-3-1/2 Fuses/Accessories Power Class Rk5

The Bussmann FRN-R-3-1/2 is a Class RK5 fuse designed for time-delay applications. This dual-element fuse operates at a voltage rating of two hundred fifty volts alternating current (AC) and one hundred twenty-five volts direct current (DC). It has an amperage rating of three point five amperes and a high interrupting rating of two hundred kiloamperes (kA) at two hundred fifty volts AC, and twenty kA at one hundred twenty-five volts DC.

• Type: Time-delay, dual-element fuse
• Rated Voltage: 250 Vac; 125 Vdc
• Interrupting Rating: 200 kAIC at 250 Vac

Product Highlights

This fuse is ideal for industrial and commercial applications where safety and reliability are crucial. It fits various safety and security systems in factories and industrial facilities.

Product Information

Standard Information

• Manufacturer: Bussmann
• Family Group: Fuses/Accessories

Technical Specifications

• Amperage Rating: 3.5 A
• Voltage Rating: 250 Vac; 125 Vdc
• Dimensions: 2.0 inches length x 0.56 inches diameter
• Connection: Ferrule end x ferrule end
• Special Features: Finger safe
• Response Time: 10 seconds at 500%
• Interrupt Rating: 200 kAIC at 250 Vac; 20 kAIC at 125 Vdc
• Certification: CE Marked
